Dart Type Check Valve
Dart type check valve provided by CCSC is available in size range 2 inch and 3 inch, 15,000psi working pressure,for extreme nitrogen and carbon dioxide services.
Features
• unlimited installation direction
• easy installation and dismounting
• a certain self-locking performance and suitable for air tight environments
Available Specification
| Nomal Size, in | Working Pressure, psi | End Connection | Flow Condition |
| 2 | 15,000 | Fig1502 M X F | Standard |
| 3 | 15,000 | Fig1502 F X M | Standard |
